Aushärten von Harz

Harz ist das wichtigste Material für den LCD/SLA-3D-Druck, mit dem sich 3D-gedruckte Objekte direkt herstellen lassen. Es ist eine Art Material zum Drucken von Objekten in 3D-Druckern, insbesondere für Desktop-3D-Drucker.

Außerdem ist Harz der einfachste Weg, um mit dem 3D-Druck zu beginnen, aber Sie könnten verwirrt sein, wenn es um die Einstellungen für Harz-3D-Drucker geht. Keine Sorge, wir sind hier, um die besten Harzeinstellungen für Anycubic Resin 3D-Drucker unten aufzuschreiben.

anycubic photon workshop resin settings

HINWEIS:

1. Wenn die Druckumgebungstemperatur unter 20 °C liegt, wird empfohlen, die Belichtungszeit um 30 % zu erhöhen und die Z-Lift-Geschwindigkeit um 30 % zu reduzieren.

2. Die Daten stammen aus dem Anycubic-Labor und dienen nur als Referenz.

3. Unterschiedliche Druckparameter und Nachbearbeitungsprozesse führen zu unterschiedlichen Ergebnissen. Wenn beim Drucken Probleme auftreten, wenden Sie sich bitte an unseren Kundendienst.

4. Die folgenden Verarbeitungsreferenzparameter sind für den werkseitigen Standardenergiezustand des 3D-Harzdruckers geeignet. Wenn die Lichtenergie angepasst wird, müssen die Referenzverarbeitungsparameter entsprechend angepasst werden.

5. Wenn Sie immer noch nicht mit den Standardparametern drucken können, wenden Sie sich bitte für professionelle Beratung an unseren Kundendienst.

Druckeinstellungen für Photon S

Resin Type Basic Resin Plant-Based Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 8s 8s 8s 8s 9s 9s 9s 9s 12s
Light-Off Time 1s 1s 1s 1s 1s 1s 1s 1s 1s
Bottom Layer Count 6 6 6 6 6 6 6 6 6
Bottom Exposure Time 60s 60s 60s 60s 60s 60s 60s 60s 60s
Z Lift Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Z Lift Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Z Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × ×

Printing Settings for Photon Mono

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2s 2.5s 2s 2s 2.5s 2.5s 2-2.5s 2.5s 4s 2.5s 2s 2s 2.5s 2.5s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 6 6 6 6 6 6 6 8 6 6 6 6 6 6 5
Bottom Exposure Time 40s 40s 40s 40s 40s 40s 40s 25-30s 40s 40s 40s 40s 40s 40s 40s
Z Lift Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Z Lift Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 6mm/s 6mm/s 4mm/s 4mm/s 4mm/s 3mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 4mm/s 4mm/s 4-6mm/s 6mm/s 6mm/s 3mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon Mono X

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2s 2s 2s 2s 2s 2s 2s 2s 4s 4s 2s 2s 2s 2s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 4 4 8 4 4 4 4 6-8 4 4 4 4 5 5 6
Bottom Exposure Time 28s 28s 30 28s 28s 28s 28s 30s 28s 28s 28s 28s 28s 28s 28s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 2mm/s 2mm/s 4mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2-5mm/s 2mm/s 2mm/s 2mm/s 4mm/s 2mm/s 4mm/s 4mm/s
Z Retract Speed 3mm/s 3mm/s 4mm/s 3mm/s 3mm/s 2mm/s 2mm/s 3-5mm/s 3mm/s 3mm/s 3mm/s 4mm/s 3mm/s 4mm/s 4mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon Mono X 6K

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2.3s 2.5s 2s 2s 2s 2s 2s 2s 4s 2s 2s 2s 2s 2s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 6 6 8 6 6 6 6 6 6 6 6 6 6 6 6
Bottom Exposure Time 23s 23s 40s 23s 23s 23s 23s 25s 23s 28s 23s 25s 25s 28s 28s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 8mm/s 8mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Z Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 2mm/s 2mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon Mono 4K

Resin Type Basic Resin Plant-Based Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2.3s 2.3s 2s 2s 2s 2s 2s 4s 2s 2s 2s 2s 2s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 6 6 6 6 6 6 6 6 6 6 6 6 6 6
Bottom Exposure Time 40s 40s 40s 40s 40s 40s 40s 40s 40s 40s 40s 40s 40s 40s
Z Lift Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Z Lift Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × ×

Printing Settings for Photon Ultra

Resin Type Basic Resin DLP Craftsman Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 2s 2s 2s 2s 2s 2s 2s 2s 2s 2.5s 2.5s
Light-Off Time 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s
Bottom Layer Count 4 4 4 6 4 4 4 4 5 5 5 5
Bottom Exposure Time 35s 35s 35s 35s 35s 35s 35s 35s 35s 35s 35s 35s
Z Lift Distance 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm
Z Lift Speed 2mm/s 2mm/s 2mm/s 5mm/s 5mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Z Retract Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Anti-Aliasing Level 4 4 4 4 4 4 4 4 4 4 4 1
Surface Frosted

Printing Settings for Photon Mono SE

Resin Type Basic Resin Plant-Based Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 1.5s 1.5s 1.5s 1.5s 1.5s 1.5s 1.5s 1.5s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 6 6 6 6 6 6 6 6
Bottom Exposure Time 30s 30s 30s 30s 30s 30s 30s 30s
Z Lift Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Z Lift Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 4
Surface Frosted × × × × × × × ×

Printing Settings for Photon Mono SQ

Resin Type Basic Resin Plant-Based Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.3s 2.3s 2.3s 2.3s 2.3s 2.3s 2.3s 2.3s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s
Bottom Layer Count 6 6 6 6 6 6 6 6
Bottom Exposure Time 23s 23s 23s 23s 23s 23s 23s 23s
Z Lift Distance 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm
Z Lift Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Z Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × ×

Printing Settings for Photon M3

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2s 3s 2s 3s 2s 2s 2s 2s 2s 4s 4s 2s 2s 2s 2s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 4 4 4 4 4 4 4 6 4 4 4 5 5 5 5
Bottom Exposure Time 23s 23s 23s 23s 23s 23s 23s 23s 23s 25s 25s 25s 25s 25s 25s
Z Lift Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Z Lift Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 6mm/s 6mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Z Retract Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 3mm/s 3mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon M3 Plus

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 1.5s 1.5s 2s 1.5s 1.5s 1.5s 1.5s 2s 2s 4s 2s 1.5s 1.5s 1.5s 1.5s
Light-Off Time 0.1s 0.1s 0.1s 0.1s 0.1s 0.1s 0.1s 0.5s 0.1s 0.1s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 3 3 3 3 3 3 3 3 3 3 4 6 6 6 6
Bottom Exposure Time 23s 23s 23s 23s 23s 23s 23s 23s 23s 23s 23s 25s 25s 25s 25s
Z Lift Distance 4mm 4mm 8mm 4mm 4mm 4mm 4mm 4mm 4mm 6mm 6mm 6mm 6mm 6mm 6mm
Z Lift Speed 6mm/s 6mm/s 2mm/s 6mm/s 6mm/s 4mm/s 4mm/s 4mm/s 6mm/s 3mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Z Retract Speed 6mm/s 6mm/s 3mm/s 6mm/s 6mm/s 6mm/s 6mm/s 4mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon M3 Max

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 3s 3s 2s 3s 3s 3s 3s 3s 3s 4.5s 3s 3s 3s 3s 3s
Light-Off Time 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2s 2.5s 2.5s 2s 2s
Bottom Layer Count 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
Bottom Exposure Time 50s 50s 35s 50s 50s 50s 50s 35s 35s 35s 30s 35s 35s 35s 35s
Z Lift Distance 10mm 10mm 8mm 10mm 10mm 10mm 10mm 10mm 10mm 10mm 10mm 10mm 10mm 10mm 10mm
Z Lift Speed 2mm/s 2mm/s 3mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 4mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Z Retract Speed 3mm/s 3mm/s 4mm/s 3mm/s 3mm/s 2mm/s 2mm/s 3mm/s 3mm/s 3mm/s 4mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon D2

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.8s 2.5s 2.5s 2.5s 2.5s 3s 2.5s 3s 2.5s 4.5s 2.5s 2.5s 2.5s 2.5s 2.5s
Light-Off Time 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s
Bottom Layer Count 6 6 5 6 5 5 6 5 5 4 5 5 5 5 5
Bottom Exposure Time 30s 28s 28s 30s 28s 35s 30s 28s 28s 35s 28s 28s 28s 28s 28s
Z Lift Distance 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm
Z Lift Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Z Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 2mm/s 2mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 16 16 16 16 16 16 16 16 16 4 1 16 16 16 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon M3 Premium

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 4s 2.5s 2.5s 2.5s 2.5s 2.5s
Light-Off Time 0.5s 0.5s 0.5s 1s 0.5s 1s 1s 0.5s 1s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 2 2 2 2 2 2 2 2 2 3 3 2 2 2 5
Bottom Exposure Time 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 30s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon Mono X2

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 4s 2.5s 2.5s 2.5s 2.5s 2.5s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5
Bottom Exposure Time 25s 25s 25s 25s 25s 25s 25s 25s 20s 25s 25s 20s 20s 20s 20s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s
Z Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon Mono 2

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ Standard Resin+ ABS-Like Resin+ Plant-Based Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 2.5s 3s 3s 4.5s 2.5s 2.5s 2.5s 2.5s 2.5s
Light-Off Time 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s 1s
Bottom Layer Count 5 5 5 5 5 5 5 5 5 5 5 5 5 5 6
Bottom Exposure Time 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s 25s
Z Lift Distance 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm 6mm
Z Lift Speed 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Surface Frosted × × × × × × × × × × × × × × ×

Printing Settings for Photon Mono X 6Ks

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ ABS-Like Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.5s 2.5s 3s 2.5s 2.5s 2.5s 3s 4s 2.5s 2.5s 2.5s 2.5s 2.5s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 5 5 5 5 5 5 5 5 5 5 5 5 6
Bottom Exposure Time 20s 20s 20s 20s 20s 20s 20s 25s 20s 20s 20s 20s 20s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 2mm/s 3mm/s 3mm/s 3mm/s 3mm/s
Z Retract Speed 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 3mm/s 4mm/s 4mm/s 4mm/s 4mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1

Printing Settings for Photon Mono M5

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ ABS-Like Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.8s 2.8s 3s 3s 2.8s 2.8s 3s 5s 2.8s 2.8s 2.8s 2.8s 2.8s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 5 5 5 5 5 5 5 5 5 5 5 5 6
Bottom Exposure Time 25s 25s 30s 30s 25s 25s 30s 35s 25s 25s 25s 25s 25s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 5mm/s 5mm/s 5mm/s 5mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 16
Image blur*3
16
Image blur*3
16
Image blur*3
16
Image blur*3
16
Image blur*3
16
Image blur*3
16
Image blur*3
16
Image blur*3
16
Image blur*3
1 1 1 1

Printing Settings for Photon Mono M5s

In normal printing mode, it is recommended to set the layer height to 0.05mm, and the other settings are:

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ ABS-Like Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 ABS-Like Resin Pro 2 Standard Resin V2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 2.8s 2.8s 3s 3s 2.8s 2.8s 3s 5s 2.8s 2.8s 2.8s 2.8s 2.8s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 5 5 5 5 5 5 5 5 5 5 5 5 6
Bottom Exposure Time 25s 25s 30s 30s 25s 25s 30s 35s 25s 25s 25s 25s 25s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 5mm/s 5mm/s 5mm/s 5mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1

In fast printing mode, it is recommended to set the layer height to 0.1mm, and the other settings are:

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ ABS-Like Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 High Speed Resin Standard Resin V2 ABS-Like Resin Pro 2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm
Exposure Time 3.2s 3.2s 3.4s 3.4s 3.2s 3.2s 3.4s 6s 3.2s 1.7s 3s 3s 3s 3s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 4 4 4 4 4 4 4 4 4 3 6 6 6 6
Bottom Exposure Time 25s 25s 30s 30s 25s 25s 30s 40s 25s 10s 25s 25s 25s 25s
Z Lift Distance 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 3mm 5mm 5mm 5mm 5mm
Z Lift Speed 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s
Z Retract Speed 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1

Printing Settings for Photon Mono M5s Pro

In normal printing mode, it is recommended to set the layer height to 0.05mm, and the other settings are:

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ ABS-Like Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 Standard Resin V2 ABS-Like Resin Pro 2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm 0.05mm
Exposure Time 3.6s 3.8s 3.8s 3.6s 3.6s 4s 4s 3.8s 4s 3.6s 3.6s 3.6s 3.6s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 5 5 5 5 5 5 5 5 5 5 5 5 5
Bottom Exposure Time 30s 30s 30s 30s 30s 35s 35s 35s 35s 30s 30s 30s 30s
Z Lift Distance 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm 8mm
Z Lift Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Z Retract Speed 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s 6mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1

In fast printing mode, it is recommended to set the layer height to 0.1mm, and the other settings are:

Resin Type Basic Resin Plant-Based Resin DLP Craftsman Resin UV Tough Resin Water-Wash Resin+ ABS-Like Resin+ ABS-Like Resin Pro High Clear Resin ABS-Like Resin V2 High Speed Resin Standard Resin V2 ABS-Like Resin Pro 2 Tough Resin Ultra Tough Resin 2.0
Layer Height 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm 0.1mm
Exposure Time 3.8s 4s 4 4s 3.8s 4.2s 4.2s 4.5s 4.2s 1.9s 3.8s 4s 3.8s 3.8s
Light-Off Time 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 0.5s 1s 1s
Bottom Layer Count 5 5 5 5 5 5 5 5 5 5 5 5 5 5
Bottom Exposure Time 30s 30s 30s 30s 30s 35s 35s 35s 35s 10s 30s 30s 30s 30s
Z Lift Distance 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 5mm 3mm 5mm 5mm 5mm 5mm
Z Lift Speed 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s
Z Retract Speed 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s 20mm/s
Anti-Aliasing Level 1 1 1 1 1 1 1 1 1 1 1 1 1 1

Anycubic bietet hochwertige und einfach zu verwendende Harze für SLA/DLP/LCD-3D-Drucker mit großer Farbauswahl. Klicken Sie auf das Bild oben, um mehr zu erfahren.
